- E-Ink Display
- Model: AA-IOT-EINK075
- The AA-IOT-EINK075 introduces the concept of low carbon into corporate management. Not only does it save enterprise costs and improve work efficiency, but it also implements national environmental policies and promotes the advancement of green and high-quality development. With low power consumption, support for Bluetooth and wireless applications, and incredible scalability, it offers economic cost and high energy efficiency. The lightweight display can be moved and adhered to walls or desktops at any angle.
- Features
- Color - Pearl White
- Lightweight
- Clear Display
- No Cables Required
- Tri-Color E-Ink
- Highly Energy-Efficient
- Smart Refresh Rate
- 5-Year Battery Life
- Bluetooth 5.0
- Device Status Description
- When Powered On
- If the device is not paired, it will enter Bluetooth mode, allowing users to pair and connect.
- If the device is paired, it will actively access the network upon startup to instantly obtain network content updates.
- Indicator Lights
- Green light on: Device is powered on.
- Green light flashing: Bluetooth pairing mode is active.
- Red light on: Device is charging (red light turns off when fully charged).
Device Details
Screen Size
4.2 inches
- Display Area (mm): 84.8063.60
- Resolution: 400300
- Pixel Density: 119dpi
- Dot Pitch: 0.2120.212
- Dimensions (mm): 9993.513.5
- Weight: 110g
7.5 inches
- Display Area (mm): 163.2497.94
- Resolution: 880528
- Pixel Density: 137dpi
- Dot Pitch: 0.18550.1855
- Dimensions (mm): 178.9124.916
- Weight: 293.2g
- Communication Method: Bluetooth 5.0
- Broadcast Power: 0dbm
- Broadcast Frequency: 300ms
- Color: White
- Screen Colors: Black, White, Red
- Operating Temperature: 0℃~50℃
- Enclosure Material: ABS Plastic, Transparent PC
- Installation Method: Stand, Adhesive
- Product Certification: BQB/CE/FCC/ROHS
- Built-in Battery Life: Ultra-low power consumption, with a lifespan of 5 years when refreshed 5 times daily
